| 圖 片 | 編 號(hào) | 位 置 | 品名尺寸 | 適用機(jī)種 | 原廠編號(hào) |
|---|---|---|---|---|---|
 |
M407 | Feed Section |
陶瓷出線輪副軸 Pinch Roller φ57*φ19*18t |
DWC-F,F1,G,H,H' CX FX,RA,QA |
X054D257G51 X054D078G51 X058D340G51 |
 |
M406 | Feed Section |
陶瓷出線輪主軸 Capstan Roller φ57*φ10*32t |
DWC-HA,C,SA,SB,SZ,SX | X053C778G51 |
 |
M405 | Feed Section |
陶瓷出線輪副軸 Pinch Roller φ57*φ19*32t |
DWC-HA,C,SA,SB,SZ,SX | X053C779G51 |
 |
M404 | Feed Section |
陶瓷出線輪主軸 Capstan Roller φ57*φ10*25t |
DWC+H1,C,90CR,90CA, SA,FA10,SK3,AF1,AF2 |
X054D412G51 |
 |
M403 | Feed Section |
陶瓷出線輪副軸 Pinch Roller φ57*φ19*25t |
DWC-H1,C,90CR,90CA, SA,FA10,SK3,AF1,AF2 |
X054D413G51 |
 |
M402 | Feed Section |
陶瓷出線輪主軸 Capstan Roller φ57*φ10*18t |
DWC-F,F1,G,H,H',CX | X054D256G51 X058D077G51 |
 |
M405-1 | Feed Section |
出線輪副軸用間隔環(huán) Space Ring For Pinch Roller 18.8*8*7 |
DWC-HA,C,SA,SB,SZ,SX DWC-FA,RA |
|
 |
M412C | Feed Section |
陶瓷出線輪主軸 Capstan Roller φ80*φ15*25t |
DWC-FA(S),BA | X085C557G51/2210004530 |
 |
M411C | Feed Section |
陶瓷出線輪副軸 Pingch Roller φ80*φ28*25t |
DWC-FA(S),BA | X085C556G51/2210004529 |
 |
M410C | Feed Section |
陶瓷出線輪主軸 Capstan Roller φ57*φ12*25t |
DWC-FA,RA | X055C009G51 |
